KAAZ Basic Type LSD

Features

As a result, when compared with other LSD brands, you will find that a KAAZ LSD offers the following advantages:

• The sensitive LSD will work even when the slightest torque is applied.
• Increased ability to transfer power from the engine to the ground without loss.
• The power acting on the plates is reduced so that abrasion on the plates are protected.
• Increased number of friction plates greatly improves abrasion efficiency and heat capacitance of the plates. Longer plate wear life.
• Not only the friction plates, but all parts of our LSD have been improved and made larger, so the overall strength of the main body is increased.

These merits gives the LSD near perfect efficiency, stable operation and long lasting outstanding control for you. For a better understanding, you can view the exploded view photo of the KAAZ LSD to see the overall product construction.

Smooth locking ability and stable drivability

KAAZ has noticed a great advantage in the use of cone springs to apply the initial torque to the clutch plates. For this reason, we still use the cone spring design like the day our first production run was made. This is a long proven design.

The cone spring is generally known to provide pressure when compressed. Normally the initial resistance is soft but as more pressure is applied the resistance increases quickly. Understanding this cone spring's character and pressure build up, our engineers have achieved a unique design to provide the smoothest engagement and locking ability into our LSD units.

In general, there is a misunderstanding that "High Initial Torque = More Effective LSD". KAAZ design is based on the LSD's overall locking characteristics and not to depend on the initial torque setting only. This makes for much smoother driver control. By controlling the LSD's effectiveness based on the accelerator input, the driver can always feel superb stability while driving. KAAZ LSD's most unique feature is the smoothness between the lock to free transfer due to it's superb design.

The LSD kit includes the following

• KAAZ LSD
• New Bearing Set Not for all vehicles Types
• New Gasket Set Not for all vehicle Types
• Instruction Manuals
• KAAZ Diff Oil
